0.5-2.0 GHz Coaxial Double Balanced Mixer J0520H

Part number J0520H

Product overview

Designed for your next RF system.





Categories: SKU: J0520H Tags:
Explore technical details Talk to an engineer →

Description

Outline 'B'

The Eclipse J0520 double balanced mixer series operates from 0.01 to 1.5 GHz. These mixers offer multi-octave bandwidth, wide DC to IF response, low conversion loss and high port-port isolation. The J0520 is available with SMA female connectors and 3 LO drive levels making it a versatile mixer product.

  • Multi-octave bandwidths
  • Broadband frequency – input and output
  • Wide DC to IF frequency response
  • Low conversion loss
  • High port-to-port isolation
